internet_as — Internet AS graph (2006)
- Description
A snapshot of the structure of the Internet at the level of autonomous systems (ASs), reconstructed by M. E. J. Newman from the BGP (Border Gateway Protocol) routing tables collected by the University of Oregon Route Views Project, for 22 July 2006. Nodes are autonomous systems, i.e. networks under a single administrative routing policy (such as Internet service providers, companies or universities), and an undirected edge connects two ASs that are adjacent in the observed BGP routes, indicating a direct peering or transit relationship. The network was symmetrized, i.e. edge directions were discarded.
The network has the following properties:
label: the AS number.
- Tags
- Technological Communication Unweighted
- Citation
-
- B. Karrer, M.E.J. Newman, and L. Zdeborova, "Percolation on sparse networks." Phys. Rev. Lett. 113, 208702 (2014). arXiv:1405.0483
- Upstream URL OK
- http://www-personal.umich.edu/~mejn/netdata
