topology — Internet AS graph (2010)
- Description
An integrated snapshot of the structure of the Internet at the level of Autonomous Systems (ASs), reconstructed from multiple sources, including the RouteViews and RIPE BGP trace collectors, route servers, looking glasses, and the Internet Routing Registry databases. The data were collected by the Internet topology project of the UCLA Internet Research Lab, which follows the methodology of B. Zhang et al.; this snapshot is the version of 10 March 2010, with connection times between 15 February and 10 March 2010. Nodes are ASs, and an edge is a connection between two ASs, annotated with the time of the connection (edge property
time); two ASs can be connected by multiple edges, each representing an individual connection in time.
- Tags
- Technological Communication Unweighted Multigraph Timestamps
- Added
- 2020-08-11
- Citation
-
- B. Zhang et al., "Collecting the Internet AS-level topology." SIGCOMM Computer Communication Review 35(1), 53-61 (2005) 10.1145/1052812.1052825 Sci-Hub
- Upstream URL OK
- http://konect.cc/networks/topology
- Networks
-
Tip: hover over a column header for a description.
Column legend
- $\left<k\right>$
- Mean degree
- $\sigma_k$
- Standard deviation of the degrees
- $\lambda_h$
- Largest eigenvalue of the Hashimoto (non-backtracking) matrix
- $\tau$
- Random walk mixing time
- $r$
- Degree assortativity
- $c$
- Global clustering coefficient
- $\oslash$
- (Pseudo-) diameter
- $S$
- Relative size of the largest component
- NPs
- Node properties
- EPs
- Edge properties
